Name: [KST] DS215MG 20g/ 3.70kg/ .05 sec HV Metal Digital Mini Servo
Brand: KST
SKU: QA84599
Price: 82600 KRW
Availability: OutOfStock
Rating: 5.0 (1 reviews)

[KST] DS215MG 20g/ 3.70kg/ .05 sec HV Metal Digital Mini Servo

41. 서보> KST

판매가격82,600 원회원 가입시 추가 할인

적립금820 원

물류창고

재고추가 재고 없음

상품번호QA84599※ 전화문의시 상품번호를 알려주세요

고객선호도★★★★★ 5.0 (1개)

품절

재입고 알림 신청하기

실시간 문의 (오전10시~오후6시)

이미지	상품명	선택

기타 필요한 옵션상품 총합계:
0원

옵션 상품을 포함하여 장바구니 담기 >

믿을 수 있는 팰콘샵, 6가지 안심 약속

99.9% 실재고

22년 전문가

확실한 기술지원

출고 전 촬영

실시간 배송알림

Since 2004

KST DS215MG 20g/ 3.70kg/ .05 sec HV Metal Digital Mini Servo (파일론 비행기용)

- HV 미니 서보

- 파일론 글라이이드에 적합한 서보입니다.

- 신뢰성이 매우 좋은 서보입니다.

KST Servos are renowned for Quality at realistic prices. From Hobby helicopters and gliders to Industrial and UAV applications KST servos have earnt a reputation for performance even under the most demanding conditions. Whether you need to win your next competition event, power a mission critical UAV or operate industrial grade machinery or robotics KST has a solution for you. Talk to our sales team today, OEM and ODM services are also available for custom installations.

Key Features:
Compact and light weight design
Excellent torque and speed
Designed for high performance RC Gliders
Excellent heat dissipation

Specifications:
Operating Voltage: DC6.0V-7.4V
Size: 23*12*27.50mm
Torque:3.70Kg.cm/7.4V; 3.10Kg.cm/6.0V
Speed:0.05sec/60°/7.4V; 0.06sec/60°/6.0V
Weight: 20g
Working Frequency: 1520us/333Hz, 800us-2200us
Motor: Φ12mm Coreless
Ball Bearing: 2BB

[팰콘샵] [KST] DS215MG 20g/ 3.70kg/ .05 sec HV Metal Digital Mini Servo

We can build servos with features like these and more!
Torque ranging from 2kg*cm to 700kg*cm
Travel speeds from 0.03s to 0.5s
Travel angles: from 40deg to 360deg
Communication protocols such as TTL. RS232, i2C, RS485 or PWM
Servo positioning and current feedback
Gear materials from plastics to titanium
Voltage ranges are also customizable from 4.8v to 28v
Size, Shape and design can be customized to your needs
A variety or motor options such as brushed, coreless & brushless
We can offer Potentiometer or magnetic induction control

Potential Applications.
1. Electric lock (anti-heft door lock servo)
2. Luggage case lock servo
3. Washing machine safety mechanism servo
4. Water/gas valve control Servo
5. Smart lamp Switch Servo
6. Camera gimbal control servo
7. UAV heavy duty servo
8. Servo Release Servo Drop
9. Curtain Servo
10. Automatic Perfume and liquids Sprayer Servo
11. Smart bike gear change servo
12. Electric car mirror servo
13. Car seat adjustment servo
14. Car window winding servo
15. Medical equipment servo
16. safety lock servo
17. Robot servo
18. Wheel servo
19. Robot arm servo
